Latecoere 298

1936

Back to the Virtual Aircraft Museum
  TORPEDO BOMBERVirtual Aircraft Museum / France / Latecoere

Latecoere 298

A multi-purpose twin-float seaplane, the prototype Late 298.01 first flew on 8 May 1936. Intended missions included torpedo bombing; horizontal or shallow dive bombing (with two bombs of up to 150 kg each); long-range reconnaissance (with extra 535 litre fuel tank); night reconnaissance; and smokescreen laying. A cantilever low-wing monoplane with an all-metal oval-section stressed-skin fuselage, the production Late 298A was powered by a 656kW Hispano-Suiza 12Ycrs engine and had a crew of three accommodated under a glazed canopy. The Late 298B version had folding wings for shipboard stowage. Armament comprised two fixed 7.5mm Darne wing guns and a third Darne machine-gun on a flexible mounting at the rear of the crew canopy. The Late 298D had a fourth crew member, and the 'one-off' unsuccessful Late 298E had a ventral observation gondola.

Some 110 Late 298 of all versions had been built by 25 June 1940 and a further 20 Late 298F (with MAC instead of Darne weapons and two additional 7.7mm machine-guns for ventral 'under-tail' defence) were built for the French Vichy regime.

The first naval escadrilles to equip with the type were T2 at Saint-Raphael and T1 at Berre in February and March 1939 respectively. Escadrilles HB1 and HB2 on the seaplane carrier Commandant Teste re-equipped with Late 298B in April and July the same year. From then on the type saw widespread service, flying overland in shallow dive-bombing attacks during the May-June 1940 'Blitzkrieg' on France and subsequently continuing to operate - mainly on reconnaissance missions - with both the Vichy and Free French forces. Several captured aircraft were used for liaison duties by the Germans. A number of Late 298 continued into the post-World War II period with the French Aeronavale.

Latecoere 298

Specification
 CREW3
 ENGINE1 x HS 12 Ycrs, 630kW
 WEIGHTS
  Take-off weight4123 kg9090 lb
  Empty weight2360 kg5203 lb
 DIMENSIONS
  Wingspan15.5 m51 ft 10 in
  Length12.6 m41 ft 4 in
  Height5.2 m17 ft 1 in
  Wing area31.6 m2340.14 sq ft
 PERFORMANCE
  Max. speed270 km/h168 mph
  Cruise speed243 km/h151 mph
  Range w/max payload800 km497 miles
 ARMAMENT3 machine-guns, 1700kg torpedo

Latecoere 298

Comments
Gabriel, e-mail, 23.06.2021 22:28

After ww2 the french capture many jumo 213 of german stock, and he made a laté 298 powered by a one jumo 213( 2100hp ) !
And he has a top speed of 400kp /h ( 290kp /h for the originale)
but the french army order other plane ( ex: do24, Nord 1400...) and he don't need but obsolet seaplane

reply

wayne Hancock, e-mail, 17.11.2006 19:00

I like the lines on this plane. I would like to know if there are plans for this aircraft. In additon is the engine a v?
V. R. Wayne H Hankok.

reply
