Aircraft Profile #3. Focke-Wulf Fw 190A

Click here to go to the Photo Gallery

PHOTO GALLERY


The Focke-Wulf Fw 190, one of the most aesthetically attractive and functionally successful aircraft to emerge from the Second World War, was the brainchild of Dipl. Ing. Kurt Tank, technical director of the Focke-Wulf Flugzeugbau. The designer of many impressive projects, Tank achieved perhaps his most spectacular success with the Fw 190. Combining a bulky air-cooled engine with a slim airframe, he produced a beautifully proportioned aeroplane which completely avoided the cumbersome rotundity of most other radial-engined fighters of the period. The Focke-Wulf's appearance at the fighting front ushered in a period of heavy losses and high-level alarm in the R.A.F. Superior in many respects to contemporary British equipment, the nimble radial-engined "Butcher-bird" forced a loss/victory ratio of at least 2/1 on Fighter Command Spitfire Vs in the first few months of its operational career.

In the autumn of 1937, the German Reichsluftfahrt-ministerium instructed the Focke-Wulf Flugzeugbau, uncommitted to any other major project, to submit a single-seat fighter design to supplement the Messerschmitt Bf 109, which had entered squadron service with the young Luftwaffe eighteen months previously. Of the twin proposals put forward by Tank, one was planned around the B.M.W. 139 radial engine while the other was based on the liquid-cooled Daimler-Benz DB 601. The climate of opinion in contemporary aviation circles was in favour of the low-drag characteristics of in-line engines, but nevertheless the radial-engined design was accepted. Considerable demand for the Daimler-Benz powerplant was partly responsible.

Detail design work commenced in mid-1938, culminating in the completion of the first prototype, designated Fw 190V1, in the spring of 1939. Designed for production by widely-dispersed sub-contractors, the aircraft had other features which strongly recommended it to the Luftwaffe. The wide-track undercarriage eliminated one of the weaknesses most noticeable in the Bf 109; and front-line maintenance requirements were cut to a minimum.

The Fw 190V1 was flown for the first time on 1st June 1939 by chief Focke-Wulf test pilot Hans Sander. After five flights the machine was handed over to the Luftwaffe for service trials at the Rechlin test establishment. Despite the lack
The first prototype was initially flown with a large ducted spinner; it is seen here after the removal of this unsatisfactory device
The first prototype was initially flown with a large ducted spinner; it is seen here after the removal of this unsatisfactory device
of forward visibility while taxiing, which was to prove fatal to inexperienced pilots later in the Fw 190's career, the Luftwaffe pilots were extremely impressed by the new fighter. The prototype displayed superb handling qualities, well-balanced controls and brisk acceleration. By October the second prototype, the Fw 190V2, was ready for testing. It was armed with two 7.9mm MG 17 and two 13mm MG 131 machine guns. After armament tests and some 50 hours of flight trials the machine, which had been plagued from the outset by engine overheating, was destroyed following a crankshaft failure.

Later prototypes differed in being powered by the improved B.M.W. 801C engine, offering 1,600hp. With strengthened engine mounts and the cockpit moved farther buck, these models were free from the heat and discomfort noticed by pilots of the earlier prototypes.

The flight trials of the Fw 190V1 had prompted an order for 18 pre-production fighters, the first batch being ready for testing in October 1940 under the designation Fw 190A-0. The eighth and subsequent A-0s were fitted with the longer-span wing, which became standard. Hermann Goering was an enthusiastic supporter of the new type, and preparations were made for quantity production in plants at Bremen and Hamburg, an initial order for 100 Fw 190A-1s being placed. The A-1 differed from late A-0 models only in its stressed engine cowling and assisted-release cockpit hood; armament comprised two MG 17s in the cowling and two in the wing roots. In June 1941 the first 30 Fw 190A-ls were delivered to the Luftwaffe for operational testing. Early examples of the A-2, with two slow-firing 20mm MG FF cannon in the wing-root positions, were already under test at Le Bourget.

June of 1941 saw the opening of hostilities with the Soviet Union and intensive Luftwaffe activity in the Mediterranean, including the conquest of Crete. The only fighter units remaining in Northern France were Jagdgeschwader 2 "Rihthofen" and Jagdgesckwader 26 "Schlageter". At the close of May JG 2 replaced JG 26 in the Brest/Cherbourg sector, the latter unit moving to the Abbeville/St. Omer airfield
The A-4/U8 fighter-bomber with underwing tanks fitted
The A-4/U8 fighter-bomber with underwing tanks fitted
complex near the Belgian border. In July Adolf Galland's famous JG 26 received its first Fw 190A-ls and A-2s, the more welcome because of the mauling their Bf 109F-2s had been suffering at the hands of R.A.F. Spitfire Vs.

The first operational encounter between R.A.F. fighters and Fw 190s in squadron service took place on 27th September 1941, and further combats followed with increasing frequency. A story current in R.A.F. circles at the time was that the new radial-engined fighters were ex-Armee de l'Air Curtiss Hawks appropriated by the Luftwaffe; but any pilot who encountered the Fw 190 personally could testify to the absurdity of this theory. No pre-war vintage fighter in the world could outfly the Spitfire V, and yet the sinister-looking "Butcher-bird" could break off combat with Spitfires at will by virtue of its 15/30km/h speed advantage. Faster and more stable in the dive, and capable of magnificent aileron turns, the Focke-Wulf fighters immediately reversed the narrow margin of superiority so painfully won by the R.A.F. over the Bf 109E and Bf 109F. The Luftwaffe was to maintain this advantage until the arrival of the first Spitlire IXs on the squadrons in July 1942.

The late summer and autumn of 1941 was a period of intense activity over the English Channel as the R.A.F. attempted to draw Luftwaffe units away from their triumphant campaign in the East, and the appearance of the Fw 190 at the front further reduced the already questionable effectiveness of this offensive.

During this period the Fw 190A-3 superseded the A-2 on the assembly lines. Powered by the 1,700hp B.M.W. 801 Dg engine, the A-3 carried two fast-firing MG 151 cannon in the wing roots, the MG FFs being moved outboard and the MG 17s retained in the cowling. One hundred examples of the A-3 were supplied to the Turkish Air Force, finished in the early Luftwaffe desert camouflage of brown/green dappling. They were preferred by Turkish pilots to the Spitiire Vb, also operated by that air force.

The first major action in which the Fw 190A participated was
The A-5/U3 Trop sub-variant with bomb-load in place
The A-5/U3 Trop sub-variant with bomb-load in place
the "Channel Dash". On the night of 11th/12th February 1942 the German capital ships Scharnhorst and Gneisenau left Brest with escorting vessels and began a hazardous voyage through the Channel on their way to safer anchorages in Kiel and Wilhelmshaven. Galland, newly promoted to Inspector of Fighters on the death of his colleague Werner Molders, had the task of providing fighter cover throughout the voyage. Available to him were 252 aircraft, consisting of Bf 109Fs drawn from JG 1, JG 2, and the fighter school at Paris; 30 Bf 110 night fighters for dawn and dusk operations and the mixed strength of JG 26, operating both Bf 109F-4s and Fw 190A-2s. The Focke-Wulfs acquitted themselves well in the almost continual combats of 12th February and Operation Thunderbolt (the official German code-name) was a heartening success for the Luftwaffe and Kriegsmarine.

On 10th March 1942 Sperrle, commander of Luftflotte 3, ordered JG 2 and JG 26 to form a fighter-bomber (Jagdbomber or Jabo) Staffel within each of the Geschwader. Initially equipped with the Bf 109F-4/B, the two Staffeln began "tip-and-run" raids against England. Ten Jabo/ JG 2, based at Caen-Capriquet, attacked Channel shipping while 10 Jabo/JG flew missions against Dover, Worthing, Brighton and other south coast towns.

The first Fw 190A to become available for evaluation by the R.A.F. was Oberleutnant Arnim Faber's Fw 190A-3, W.Nr. 313. Oblt. Faber, the adjutant of III/JG 2, landed his machine at R.A.F. Pembrey on the evening of 23rd June 1942. Although his Staffel (7/JG 2) had been in combat with Spitfires of the Exeter-based Polish Wing returning from a strike on Morlaix airfield, Faber's Focke-Wulf was undamaged, and his reasons for landing are obscure. The most likely theory, that he mistook the Bristol Channel for the English Channel and thought he was landing at a Luftwaffe airfield in Northern France, is borne out by the series of victory rolls he performed before touching down. Faber's garishly-painted aircraft was immediately examined by R.A.F. and industrial experts and service pilots; their findings substantiated the reports received from aircrew on
A view of the 190A-4/R5, with overwing tank experimental installation
A view of the 190A-4/R5, with overwing tank experimental installation
the squadrons, and seriously influenced British thinking in fighter design for the future. An example of the trend is the Hawker Tempest II; the conception was finally perfected in the Hawker F.2/43 Fury.

By 20th July 1942, the day of the costly "reconnaissance in force" by Canadian troops at Dieppe, 10 Jabo/JG 26 was flying Fw 190A-4s. The A-4 subtype was powered by a B.M.W. 801D-2 engine with MW 50 fuel injection, raising the maximum speed to 670km/h. Formations of JG 26 were active over the beaches and town of Dieppe during the raid. Two months later, the Jabo units of both JG 2 and JG 26 were equipped with the Fw 190A-4/U8; armed with two MG 151 cannon in the wing roots, this variant could carry 500kg of bomb load and two 300-litre wing tanks. The task of intercepting the Jabo raids became increasingly difficult. Approaching the English coast at wave-top height, pairs of Focke-Wulfs avoided the radar defences and were diving southwards again at full throttle before R.A.F. Spitfires could locate them. Fighter Command began tedious and uneconomical standing patrols and it was not until the operational appearance of the Hawker Typhoon that this threat to the morale of the population was countered. Insignificant in terms of military results, these pin-prick raids caused a reaction from the R.A.F, out of all proportion to the Luftwaffe's efforts.

The first raids on French targets by the 8th U.S.A.A.F.s B-17 Flying Fortresses were carried out in August 1942, and by the end of the year the Fw 190A-equipped Staffeln of JG 2 and JG 26 could no longer be spared for fighter-bomber duties. In the spring of 1943 a new unit, SKG 10 (Snellkampfgeschwader or Fast Bomber Wing) was formed, equipped with the Fw 190A-4/U8. Initially operating under the Fliegerführer Atlantik on anti-shipping strikes in the Bay of Biscay, SKG 10 was transferred in early summer to the Amiens area, and took up the Jabo offensive abandoned by JG 2 and JG 26. In July II, III, and IV/SKG 10 were rushed
The Fw 190A-4/R6 was fitted with two WG 21 rocket launchers or bomber interceptor duties
The Fw 190A-4/R6 was fitted with two WG 21 rocket launchers or bomber interceptor duties
to Sicily, and the Focke-Wulfs of I/SKG 10 continued operations over the Channel until early in 1944. The Gruppe even took part in night intruder missions over London and the Home Counties.

The close of 1942 saw full-scale production of the Fw 190A and the manufacture of components in many plants throughout Germany and the occupied territories; among others, some Fieseler and Ago factories were switched to this programme. The Luftwaffe had received over 1,900 examples of A-3 and A-4 fighters and A-4 fighter-bomber variants during the year. The Fw 190A-5 appeared early in 1943. Essentially the same aircraft as the A-4, this next production variant different only in its improved engine mountings, which necessitated the engine being moved 15cm farther forward.

Of all theatres of operation where the Fw 190 was needed, North Africa presented the most pressing problem. In the early spring of 1943 Erwin Rommel's forces were fighting a hopeless rearguard action in Tunisia, and their airborne lines of communication across the Mediterranean were being ravaged by Allied fighters. The two desert fighter formations, JG 27 and Jagdgeschwader 53 "Pik As", had been reduced to a pitiable condition, and the newly-drafted JG 77 and II/JG 51 were suffering heavy losses. Units of Fw 190A-4/Trops, with desert filters and fuselage racks for a 250kg bomb enjoyed a fair measure of success in operations with the Fliegerführer Tunis, but even so the campaign ended in costly defeat in May 1943. A quarter of a million men of the Afrika Korps surrendered and the Fw 190s took part in a hurried evacuation of Luftwaffe personnel to Sicily, carrying as many as three men per aircraft.

The Allied invasion of Sicily followed on 10th July and Fw 190A-4/U8s, A-4/Trops, and A-6/R2s (a model with 750kg bomb load capacity) were heavily committed in operations with Kesselring's Luftflotte 2. By the time these units (including II, III, and IV/ SKG 10) were withdrawn to Italy they had suffered crippling losses.

Another type of operation in which the Fw 190A gained good initial results was free-lance night
Fw 190A in scheme adopted for Home Defence duties late in the war. The fuselage bands appeared variously in red/yellow, blue/white or black/white. Blue/white was the most widely used style in 1945. Machine illustrated probably belonged to II/JG 4
Fw 190A in scheme adopted for Home Defence duties late in the war. The fuselage bands appeared variously in red/yellow, blue/white or black/white. Blue/white was the most widely used style in 1945. Machine illustrated probably belonged to II/JG 4
fighting. This venture was instigated by a Luftwaffe ex-bomber pilot, Major (later Oberst) "Hajo" Herrmann, whose private experiments in single-seater fighter operations against R.A.F. Bomber Command's night offensive in the spring of 1943 resulted in the formation of 30 Jagd Division, comprising JGs 300, 301, and 302. Despite complaints from orthodox night lighting formations that these Wilde Sau (Wild Boar) aircraft were causing serious confusion in the crowded night skies, the volunteer pilots were the darlings of Press and public as their scores mounted. Aircraft used in these operations were the Fw 190A-5/U2, with flame-dampers and anti-glare screens and the Messerschmitt Bf 109G-6/U4N. By the winter of 1943 both aircraft and pilots had been "flown to death", and losses mounted; 30 Jagd Division was withdrawn from night operations early in 1944 and underwent conversion to various "dirty-weather" and special duties roles, including bomber interception.

As stated above, the 8th U.S.A.A.F. began operations from England in August 1942 and these first insignificant raids were the forerunners of the immense formation attacks by B-17s and B-24 Liberators which during the next three years shattered the German industrial machine and German morale. At the outset of the offensive only JGs 1, 2, and 26 were available to defend the western approaches of the Reich against daylight bombing; two years later nine Geschwader proved inadequate, and this drain on resources seriously aggravated the situation on the Russian front.

Fw 190As equipped many first-line units of the Reichsverteidigung (Luftwaffe Home Defence Command). The rapidly increasing numbers of Allied escort fighters and their unexpected improvement in range led to a continuous series of air battles over the Netherlands, France and Germany in which the North American P-51 Mustangs and Republic P-47 Thunderbolts inexorably wore down the strength of the Luftwaffe. New tactics and new weapons were evolved for the Jogdgesckwader (an example is the WG 21 "Dodel" racket launcher fitted to the Fw 190A-4/R6) but despite the spirited resistance of the German fighter pilots, which earned them the ungrudging admiration of the American aircrews, sheer weight of numbers was
Fw 190A abandoned at Salerno after Allied successes
Fw 190A abandoned at Salerno after Allied successes
on the side of the Allies. The output of new fighters from the factories was stepped up in an intensive effort which was a credit to the industry, but useless in the long run.

In respect of armament the Fw 190A variants were slightly superior to the Bf 109G models, but the Fockc-Wulf's performance fell off badly above 6000m, the height at which the bombers usually operated. Even when the escort fighters were evaded, a Luftwaffe pilot attacking a combat "box" of 18 B-17s had to face a combined defensive armament of more than 200 heavy machine guns, and while the Fortresses were by no means invincible, it required a fighter pilot of considerable skill and determination to press home attacks on such a formation with his four 20mm cannon.

In the winter of 1943-44 Fw 190As were fitted with additional armour for a new role - that of "storm-fighters". A Major von Komatski had suggested to Galland that special suicide squadrons should be formed to ram the "Ami" bombers, especially the lead aircraft. Turning down this plan on principle, Galland approved the formation of an experimental Sturmstaffel whose task would be to press home attacks in tight formation at close range, whatever the cost. As a last resort, the pilots were to ram and bale out: an optimistic view of the results of a mid-air collision at combined speeds of up to 1100km/h. This volunteer unit achieved excellent results and the first Sturmgruppe was formed. It was Galland's intention to add a Sturmgruppe to each of the Reichsverteidigung Geschwader, but the invasion of Normandy interrupted this programme. The aircraft used by the Sturmgruppe was the Fw 190A-5/U16.

The other major sphere of action in which the Fw 190 participated was "the Verdun of the air" - the savage fighting on the Russian front. Despite the fact that the Focke-Wulf was opposed in this theatre by aircraft of inferior design and performance, it gained for the Luftwaffe no lasting margin of air superiority. The cause of this failure did not lie in any technical
Installation of racks for eight small 50-kg bombs on the Fw 190V-8
Installation of racks for eight small 50-kg bombs on the Fw 190V-8
shortcomings, it was simply part of the overall inability of the German air arm as a whole to cope with the special circumstances encountered in this campaign.

In the early hours of 22nd June 1941 the forces of the Third Reich began their massive offensive in the East on a front of more than 3000km. In spite of the huge number of obsolete Soviet aircraft destroyed on the ground and in the air in the initial stages of the campaign, the elimination of the Red Air Force as an effective arm was never achieved. The main centres of aircraft production remained beyond the range of the Luftwaffe's bombers, and the flow of replacements continued to reach the often depleted squadrons.

The structure of the Red Air Force placed the Luftwaffe at a disadvantage from the outset. A tactical arm of the Soviet ground forces, it was geared to the task of supporting the Red Army on a wide front as "aerial artillery", and although equipment and standards of flying were somewhat crude by Western criteria, the MiGs, LaGGs and Ilyushins performed their task admirably.

As the area of operations in Russia constantly expanded and shifted, the type of operation most favourable to the Luftwaffe - the assembly of numerically and qualitively superior forces at a limited number of key points - became largely irrelevant. The physical scope of the campaign and the dauntingly primitive conditions in the field struck at the sophisticated and therefore sensitive structure of the Luftwaffe. The length of lines of communication, the consequent delays in supply, and the limited numbers of units available conspired to rob the Luftwaffe's fighter Gruppen of their initiative, to distort their correct employment, and to condemn them to continual sacrifice in "penny packets" on a wide front, frittering away men and machines in a horrifying war of attrition.

A fine example of the fatal incongruities forced upon the Luftwaffe in Russia is the fact that in 1943 JG 54 "Grunherz", a veteran interceptor unit, was equipped with the Fw 190F-8 ground attack aircraft. The suitability of
An Fw 190A-5/U3 Trop fighter-bomber of I/SG 4
An Fw 190A-5/U3 Trop fighter-bomber of I/SG 4
the Fw 190 for fighter-bomber duties led to constant competition between fighter and fighter-bomber units for the insufficient supplies of these machines,

Fw 190A fighters first appeared on the Russian front with I/JG 51. This unit was re-equipped in time to take part in the counter-offensive of early July 1943, and distinguished itself in action against units of the 1st, 4th and 16th Soviet Air Armies. In the ground attack role, the Focke-Wulf had reached Schlachtgeschwader 1 (Ground Attack Wing No. 1) in April of that year, in the Kursk salient. From late summer Korten, the new Luftwaffe Chief of Staff, instituted a vigorous programme of re-equipment in the ground attack units, replacing ageing Junkers Ju 87Ds with Fw 190 variants. Despite conflicting demands on the production lines, Schlachtgruppen were soon being re-equipped at a rate of about two every six weeks. Ground attack versions of the Fw 190A to appear at the front during these months were the A-5/U3 and A-5/U8, with light armament and large bomb load capacity, and the heavily-armed A-5/U11 with only 450kg bomb load capacity.

During 1944 the Ju 87D was largely relegated to night operations and the Fw 190 took over daylight missions, although hampered by shortages of ammunition, tyres and fuel.

By the early months of 1944, the Luftwaffe was in a precarious position on all fronts. The Russian "steamroller" was grinding westward over the remains of the once-triumphant German forces. The Allied bombing offensive was causing serious shortages of synthetic fuel and components, and many Jagdgeschwader veterans had died in attacks on Fortress and Liberator '"boxes". The training establishments were stepping up their output of raw pilots whose life expectancy could be measured in days. The ultimate collapse was still a year away, but it was already predictable. An ominous symptom was the growing number of Luftwaffe personnel being pressed into service as infantrymen, artillerymen, or SS troopers; and many units had disappeared entirely, to be hurriedly replaced by composite formations.

Fearful for their depleted fighter units in Northern France, the Luftwaffe High Command ordered the
Fw 190A-4 nose armament - two MG 17 machine-guns
Fw 190A-4 nose armament - two MG 17 machine-guns
dispersal of the Gruppen of JG 26 away from the intensive Allied bombing of the invasion coasts in May/June of 1944. Thus it was that on the morning of 6th June the only fighter forces to launch an attack on the Normandy beaches were two Fw 190As! They were the machines of Oberst Josef "Pips" Priller, the flamboyant Geschwaderkommodore of JG 26, and his rottenftieger (wingman) Feldwebel Wodarczyk. I/JG 26 had flown to Rheims, II/JG 26 to Mont de Marsan in Gascony, and III/JG 26 to Metz. The two pilots' strafing run was the only Luftwaffe activity over the beachhead during the daylight hours of D-Day.

The already-overstretched fighter units were immediately re-deployed to contest the Allied advance in the Cotentin peninsula; and many Gruppen were decimated above the holocausts of Caen and St. Lo. III/JG 54 operated from Villacoublay, and suffered 50% losses in pilots and 70% losses in its Fw 190As. The Fw 190A-4/U8s or SKG 10 flew from Dreux for a few days until the unit was virtually annihilated.

Few of the Jagdgeschwader long survived the battles over Normandy as organised tactical units. Retreating across Europe, some formations operated from concealed bases under more or less improvised conditions, with little or no contact with higher authority. By mid-winter of 1944 Allied bombs had destroyed the last synthetic fuel refineries, and remaining stocks were jealously regulated. On New Year's Day 1945, about 650 Fw 190s of JGs 2, 3, 4, 26, and several other units took part in Operation Hermann, Goering's last ditch attempt to cripple the Allied air component in Europe by destroying their aircraft on the ground. Many Luftwaffe pilots were so pitifully inexperienced that they had to be guided to their targets by master-navigators in Ju 88s. The dawn raid gained good results in terms of aircraft destroyed, and increased the strain on the pilots whose machines survived, but the Allies' vast industrial capacity could quickly make good the losses, R.A.F. and U.S.A.A.F. casualties were not heavy, and the Luftwaffe lost more men and machines than they could
The A-4 variant, seen here in an unusual colour scheme employed by JG 54 in Russia
The A-4 variant, seen here in an unusual colour scheme employed by JG 54 in Russia
afford at that stage.

By mid-February 1945 the Russians had captured Fw 190 component, assembly and repair facilities at Marienburg, Sorau, Riga, Warsaw, Posen, Breslau, Liegnitz and Kreising; the Marienburg and Sorau plants alone represented 25% of all Fw 190 production. In March the last stocks of fuel were issued; and the following month many brand-new examples of the Focke-Wulf Flugzeugbau's graceful fighter stood with dry fuel tanks on their battered dispersals, under heavy camouflage, or in tunnels beside Autobahn-runways. More than 20,000 had been built, the vast majority Fw 190A variants; but the other branches of Luftwaffe organisation broke down before many of them could be used in action.

It is an interesting comment on the versatility of this most attractive of German fighters that one of its last roles before hostilities ceased was that of torpedo-bomber wilh a Kampfgeschwader. The three A-5/U15 torpedo-carrying Fw 190s built were operated by III/KG 200 in attacks on bridges in the winter of 1944-45; and other formations of this infamous "special duties" Geschwader were working-up with the "Mistel” or "Beethoven" combination weapon, with a Focke-Wulf as the carrying aircraft and a converted Ju 88A-4 as the "flying bomb". Operating from Berlin in 1945, KG 200 flew "Beethovens" against Russian bridges on the Oder.

LUFTWAFFE UNITS

The basic Luftwaffe tactical unit was the Geschwader. A fighter Geschwader (Jagdgeschwader or JG) usually comprised three Gruppen, each of which was in turn made up of three Staffeln. The operational strength of these groupings varied considerably, but a Jagdstaffel usually mustered between twelve and sixteen aircraft (the latter figure was official policy from 1943 onwards). The average Jagdgeschwader thus had an establishment of about 110-140 aircraft. Gruppen and Staffels were numbered independently. Thus II/JG 2 (the second Gruppe of JG 2) comprised the fourth, fifth, and sixth Staffeln of JG 2; and 7/JG 2 (the seventh Staffel of JG 2), 8/JG 2 and 9/JG 2 together made up III/JG 2. Some Jagdgeschwader mustered four Gruppen at some time during their life (e.g. JGs 2, 27, 51, 54) but this was not the general rule.
