Dewoitine D 570

1933

Back to the Virtual Aircraft Museum
  FIGHTERVirtual Aircraft Museum / France / Dewoitine

Dewoitine D 570

At the end of March 1933, criticism of the gulled wing of the D 560 led Emile Dewoitine to replace this with a wing of classic parasol form and of marginally reduced span and area. Re-designated D 570, the modified prototype entered flight test on 27 November 1933, transferring from Francazal to the Centre d'Essais at Villacoublay early in December. It flew back to Francazal for minor modifications, and, on 21 December, while returning to Villacoublay, suffered an aileron failure and was destroyed.

Specification
 WEIGHTS
  Take-off weight1709 kg3768 lb
  Empty weight1284 kg2831 lb
 DIMENSIONS
  Wingspan11.58 m38 ft 0 in
  Length8.53 m28 ft 0 in
  Height3.42 m11 ft 3 in
  Wing area17.00 m2182.99 sq ft
 PERFORMANCE
  Max. speed338 km/h210 mph
