McDonnell Douglas DC-10

1970

Back to the Virtual Aircraft Museum
  PASSENGER AIRCRAFTVirtual Aircraft Museum / USA / McDonnell Douglas

McDonnell Douglas DC-10

First flight of original DC-10 Series 10, 29 August 1970; certified 29 July 1971; last delivery Spring 1989. A total of 446 DC-10 aircraft was built. The last one was built in 1990.

McDonnell Douglas DC-10

Specification
 CREW3
 PASSENGERS270-343
 ENGINE3 x GE CF6-6, 178.1kN
 WEIGHTS
  Take-off weight185970 kg409996 lb
 DIMENSIONS
  Wingspan47.3 m155 ft 2 in
  Length55.3 m181 ft 5 in
  Height17.7 m58 ft 1 in
  Wing area329.8 m23549.93 sq ft
 PERFORMANCE
  Max. speed925 km/h575 mph
  Cruise speed965 km/h600 mph
  Ceiling9965 m32700 ft
  Range w/max.fuel5900 km3666 miles

McDonnell Douglas DC-10

Comments
Barry, 08.01.2014 17:29

Bangladesh Birman still operate the DC10-30 to this date, and in fact are the last airline to do so on scheduled passenger routes. These venerable aircraft are due for repalcement later this year and or early next year.

reply

nduduzo, e-mail, 11.01.2013 11:11

I'm fascinatet by aircrafts the dc 10 has its place in my heart I like it

reply

Dale Myers, e-mail, 26.10.2011 21:24

I flew the 10 out hnl for Northwest Loved it.

reply

Mike Miller, e-mail, 25.06.2011 08:51

Flew the KC-10 1985 to 1987 for the USAF Reserves. What a great airplane and a great mission!

reply

Ed Madigan, e-mail, 05.05.2011 05:34

Flew the DC-10 for Western Airlines. Great Flight Management system. Turn off the auto pilot and it was a very stable machine to fly. My favorite airliner to fly.

reply

Richrd Franchi, e-mail, 05.05.2011 01:55

Correction....flew the 10 fron 1976 to 1996...Richard

reply

Richard Franchi, e-mail, 05.05.2011 01:53

Flew the 10 from 1996 to 1995. With it through good and bad. After getting to know her real well.....frm DC-6 to the 10........the 10 made life a lot more fun.

reply

Bryan, e-mail, 27.02.2011 05:07

Sweetest Plane I ever flew, way ahead of It's time

reply

Steve, e-mail, 19.02.2011 22:03

don't forget the P&W powered DC10-40 flown by Northwest and JAL

reply

Russ Adams, e-mail, 13.12.2010 02:57

Don't be scared JD. I did alot of work on this bird, and it was a nice solid airplane. The #2 engine was a little tough in a line operation but in a properly equipped hangar with a good crew everything went fine. Actually it really beats any Airbus for structure simplicity and logic.

reply

JD, e-mail, 24.04.2010 23:43

THIS WAS THE SCARIEST PLANE I WAS EVER ON. AFTER 25 MAY 1979.

reply

Bill, e-mail, 03.02.2010 05:17

I agree with Seth! How can you have a cruise speed that is 50 mph higher than max speed? 32,700 seems quite low as I have flown DC-10's up to 42,000.

reply

Seth, e-mail, 08.10.2008 03:48

Yes, I have a comment. Your data is wrong. There are 4 different models of DC-10. The KC-10A Extender is a DC-10-30CF and its unrefueled range is 10,000nm, not 3666. There are other inaccuracies (max weight, ceiling, cruise speed, etc.), but I don't have enough time to correct them.

reply
