  AERIAL PHOTOGRAPHYVirtual Aircraft Museum / USSR / Russia / Antonov

Antonov An-30

Twin-turboprop aerial survey aircraft. First flown 1974; built in small numbers.

Antonov An-30

Specification
 CREW6-7
 ENGINE2 x turbo prop AI-24VT, 2075 kW and turbo-jet RU-19A, 7.8kN
 WEIGHTS
  Take-off weight23000 kg50707 lb
  Empty weight15950 kg35164 lb
 DIMENSIONS
  Wingspan29.2 m96 ft 10 in
  Length24.3 m80 ft 9 in
  Height8.3 m27 ft 3 in
  Wing area75.0 m2807.29 sq ft
 PERFORMANCE
  Max. speed540 km/h336 mph
  Cruise speed430 km/h267 mph
  Range2600 km1616 miles
