| There is no text information for this aircraft at the moment.
| mali, 18.06.2011 06:01 In 1937 based on the experiences from the Ki-5, a low-wing all-metal monoplane, but the army favoured Nakajima Ki-27 & give up this one. reply | | Denis, e-mail, 08.08.2008 12:35 Specifications for the Ki-28 were
Crew 1.
Length 12 Mtrs.
Wingspan 7.9 Mtrs.
Wing area 19 Sq Mtrs.
Height 2.6 Mtrs.
Empty weight 1420 Kgs.
Max Take off Weight 1760 Kgs.
Power Plant 1 x Kawasaki Ha-9-IIa 800hp 12 cyl in line liquid cooled engine.
Max Speed 485 km /hr.
Range 1000 Km.
Ceiling 11000 Mtrs. reply | | Denis, e-mail, 08.08.2008 12:16 The Ki-28 was Kawasaki's competitor to fill a requirement for a replacement fighter in 1935 for the Japanese Army Air Force (JAAF). It was pitted against the Mitsubishi Ki-33 and the Nakajima Ki-27. All three aircraft were low wing monoplane design and similar in performance but the Ki-27 won out due to its manoeuverability. The Ki-28 was powered by an 800 hp Kawasake Ha-9-IIa liquid cooled engine. Ref Japanese Aircraft of the Pacific War by Rene J Francillon. reply | | leon, e-mail, 30.01.2008 11:39 In 1937 based on the experiences from the Ki-5, a low-wing all-metal monoplane, but the army favoured Nakajima Ki-27 & give up this one. reply |
|
