| There is no text information for this aircraft at the moment.
CREW | 1 |
PASSENGERS | 2 |
ENGINE | 1 x 140hp Cirrus Hermes IV or 135hp Armstrong Siddeley Genet Major I |
WEIGHTS |
Take-off weight | 842 kg | 1856 lb |
Empty weight | 518 kg | 1142 lb |
DIMENSIONS |
Wingspan | 9.14 m | 30 ft 0 in |
Length | 7.54 m | 25 ft 9 in |
Height | 2.67 m | 9 ft 9 in |
Wing area | 24.25 m2 | 261.02 sq ft |
PERFORMANCE |
Max. speed | 177 km/h | 110 mph |
Cruise speed | 153 km/h | 95 mph |
Ceiling | 4115 m | 13500 ft |
Range | 523 km | 325 miles |
