Armstrong Whitworth Argosy

1926

Back to the Virtual Aircraft Museum
  TRANSPORTVirtual Aircraft Museum / United Kingdom / Armstrong Whitworth

Armstrong Whitworth Argosy

There is no text information for this aircraft at the moment.

Armstrong Whitworth Argosy

Specification
 MODELArgosy Mk I
 PASSENGERS20
 ENGINE3 x 385hp Direct-Drive Jaguar
 WEIGHTS
  Take-off weight8165 kg18001 lb
 DIMENSIONS
  Wingspan27.64 m91 ft 8 in
  Length20.07 m66 ft 10 in
  Height6.05 m20 ft 10 in
  Wing area175.22 m21886.05 sq ft
 PERFORMANCE
  Max. speed177 km/h110 mph
  Cruise speed153 km/h95 mph
  Range531 km330 miles

3-View
Armstrong Whitworth ArgosyA three-view drawing (900 x 780)
