Aviatik (Berg) 30.24

1917

Back to the Virtual Aircraft Museum
  FIGHTERVirtual Aircraft Museum / Austria / Aviatik

Aviatik (Berg) 30.24

The Aviatik 30.24 (this designation indicating that it was the 24th experimental aircraft produced by O-UF Aviatik) single-seat fighter triplane designed by von Berg appeared in May 1917. Employing a similar structure to that of the D.I and a basically similar fuselage, the Aviatik 30.24 was powered by a 200hp Austro-Daimler engine and carried an armament of two synchronised 8-mm Schwarzlose 07/12 machine guns. Performance was marginally inferior to that of the similarly- powered D.I, and only one prototype of the triplane was therefore completed.

Specification
 WEIGHTS
  Take-off weight862 kg1900 lb
  Empty weight620 kg1367 lb
 DIMENSIONS
  Wingspan7.22 m24 ft 8 in
  Length6.86 m23 ft 6 in
  Height2.75 m9 ft 0 in
  Wing area22.50 m2242.19 sq ft
 PERFORMANCE
  Max. speed174 km/h108 mph

Comments
lxbfYeaa, e-mail, 14.03.2024 04:01

20

reply

lxbfYeaa, e-mail, 14.03.2024 04:01

20

reply

Stephen, e-mail, 25.10.2012 01:32

Three prototypes of 30.24 were built. One in 1917 and two others in 1918. They were accepted by K.u.K in October 1918.
